Daiwa 22 Exist LT5000D-C Spinning Fishing Reel

The flagship spin reel in the Daiwa light tackle range once again elevates spin reel design to a new level with the release of the 22 Exist. A beacon of design possibility and performance since the original Exist was released in 2006, the 22 models introduces new designs and technologies to deliver anglers their most advanced light tackle Daiwa spin reel to date.

The foundation of the 22 Exist’s design is Daiwa’s new Airdrive Design, a four pillar (Airdrive Rotor, Airdrive Bail, Airdrive Spool, and Airdrive Shaft) design concept that reduces weight, and enhances rotational smoothness and responsiveness to create a reel that is next level in both form and function.

The new Airdrive Rotor and Airdrive Airbail combine to reduce weight at the top of the reel to improve rotational smoothness and start up speed, and to minimise rotational resistance and inertia. These design benefits are further enhanced thanks to the Exist’s new weight-saving, optimally balanced Airdrive Spool.

The last of the four key features of Airdrive Design, Airdrive Shaft, features a low contact structure between the mainshaft and pinion, and results in reduced internal friction and improved rotational smoothness.

A leap forward in Daiwa light tackle spin reel design, Daiwa’s Airdrive Design concept combines with proven Daiwa technologies including Monocoque Body, Magseal, Tough Digigear, ATD, and Twistbuster, to deliver anglers their most advanced Exist reel ever.

Lighter, smoother, more balanced and free flowing than ever before the 22 Exist delivers the future in the angler’s hands.

Features:

• Monocoque
• Air Bail
• Air Rotor Lightweight Roto
• Aluminum Handle
• Tough Digigear
• Magnesium Body
• Magsealed Body
• ATD (Automatic Tournament Drag) Type-L Drag Technology

Technologies

Monocoque:

DAIWA’s latest technology MONOCOQUE BODY is made by an integral molding system to create a rigid one piece body. By removing the traditional screws used to attach the sideplate, internal space is maximised within the gear housing. The MQ BODY uses a large diameter engine plate to screw on to the body to seal the internals. The extra space created in the MONOCOQUE BODY allows DAIWA to install a larger diameter drive gear into a smaller size reel. This system instantly creates the more durable reel inside and out.

Touch Digigear:

The drive gear within any reel is made from 3 key elements which cannot be missed. (Design Creativity, Processing Technology and Premium Quality Material)

22 EXIST consists of all 3 key elements.

The latest digital analysis and machine cut technology is used to create a perfect surface on each tooth of the drive gear. By using the latest premium Duralumin material, precision designs deliver an incredibly smooth rotation quality.

Magsealed:

During the design process of 22 EXIST key areas for water ingress were analyzed. The introduction of MQ body prevents water intrusion within the body, whilst areas of rotation or areas frequently exposed to water have been equipped with MAGSEALED/MAGSEALED BALL BEARING technology. Sections of the reel which are not key rotational areas are equipped with strong rubber seals. Anglers will come to understand this level of quality from 22 EXIST.

ATD TYPE-L:

New ATD TYPE-L drag technology improves the initial drag system response. Lowering the peak drag max upon hook setting. Light tackle fishing especially requires a responsive and sensitive adjustment of the drag pressure.

ATD TYPE-L allows anglers to have more control of the drag without stress during the fight. By not overloading the line and also causing less stress to the fish, powerful fish can be tamed easily with 22 EXIST.
